Yokogawa CA51 Handy CAL Calibrator CA51 Multifunction Calibrator
Overview of Yokogawa CA51 Handy CAL Calibrator CA51 Multifunction Calibrator
The CA51/CA71 HANDY CAL calibrators are comprehensive generating/measuring instruments for all your calibration and equipment checking needs at maintenance sites. The CA51/CA71 can simultaneously generate and measure voltage, current, TC, RTD and pulse signals, thus you don’t need to prepare many instruments. In addition, the incorporated rotary switches of good repute enable operations so smooth that an incorrect measurement caused from erroneous operations can be prevented.
The CA51 Handy Calibrator is a basic model with the same functions as the CA71 except TC and RTD measurement functions and online communication functions.
Multifunction Calibrator w/out Temperature of Yokogawa CA51 Handy CAL Calibrator CA51 Multifunction Calibrator
* Source and measure operations can be performed at the same time
* Select from the following source signal and measurement signal options:
* Voltage, Current, Resistance and Frequency
* AC voltages, including supply voltage, can be measured
* Easy operation
* Compact size and Lightweight design
Characteristics of Yokogawa CA51 Handy CAL Calibrator CA51 Multifunction Calibrator
* AC voltage (including supply voltage) measurement capability: In cases where numerous signal converters and other devices are mounted on a rack or panel, the Handy Calibrator can be used to check the input and output signals of each device, while simultaneously checking the power supply.
* A wide array of useful functions
* Source: Values set in steps of 4-20 mA, 24V DC Power supply to transmitter
* Divided output (n/m) function: Output settings are divided (n/m), eliminating the need for bothersome calculations for percentage output
* Auto step function: Changes the output value in step form based on the setting from the divided output (n/m) functions. Changes can be generated automatically every 10% or 25%
* Sweep functions: Linearly raises or lowers the output. The raising/lowering time can be set to either 16 or 32 seconds
* Memory function: Source values and measurements forming individual value sets can be saved to or loaded from the Handy Calibrator’s internal memory (maximum 50 value sets)
* Easy operation: The Handy Calibrator incorporates rotary switches for simple handing. Just open the carrying case cover and connect the cables, and you’re ready to take measurements
Product Description of Yokogawa CA51 Handy CAL Calibrator CA51 Multifunction Calibrator
Comprehensive source/measure instruments for all your calibration and equipment checking needs at maintenance sites. Sensors and instruments require a wide variety of operation checks in the field. The CA51 Handy Calibrator is a basic model with the same functions as the CA71 except TC and RTD measurement functions and online communication functions.
Manufacturer Specs of Yokogawa CA51 Handy CAL Calibrator CA51 Multifunction Calibrator
Auto-Step Output Function n value sent automatically when n/m function selection is selected (two options: approximately 2.5 seconds/step or approximately 5 seconds/step)
Sweep Functions Sweep time (two options: approximately 16 seconds or approximately 32 seconds)
Memory Function 50 value sets (generated and measured values are stored as value sets with the same address (up to 50 value sets can be stored))
Measuring Unit Maximum Input Voltage terminal: 300 V AC Current terminal: 120 mA DC
Current Terminal Input Protection Fuses: 125 mA/250 V
Measuring Unit Ground Voltage Maximum 300 V AC
Measurement Display Updating Rate Approximately once per second
Serial Interface Enabled when communication cable (RS232) is connected; sold separately as optional accessory
Display Segmented LCD (Approx. 76 mm ° 48 mm)
Backlight LED backlight; auto-off after one minute (from when LIGHT key is turned on)
Power Supply Four AA alkaline batteries, or special AC adapter (sold separately)
Battery Life Measurement off, output 5 V DC/10 kO or greater: Approximately 40 hours Simultaneous signal generation/measurement, output 5 V DC/10 kO or greater: Approximately 20 hoursSimultaneous signal generation/measurement, output 20 mA/5 V: Approximately 12 hours (using alkaline batteries, with backlight off)
Auto-Power-Off Function Approx. 10 minutes (auto-power-off can be disabled through a DIP switch setting)
